Wednesday, December 30, 2009

Pringle Swithces

Below are some components of a Pringle Switch we recently refurbished. There was very little arcing on the makeup portions, but the pivots were in bad shape from mechanical wear. The customer sent in the effected parts to be serviced. We disassembled the movable and stationary bolt up areas, cleaned and filled all the gouged portions, and then silver plated all the copper. The resulting pieces were the same, if not better than brand new parts.



Give us a call to see what we can do for you!

Tuesday, December 15, 2009

ITE KCS Electrical Contacts

An assortment of electrical contacts from an ITE KSC air circuit breaker.

Monday, December 14, 2009

GE Magne Blast AM 4.16-75-0 Electrical Contacts

Newly repaired electrical contacts from a General Electric Magne Blast AM 4.16-75-0 Circuit Breaker. Use the contact information on the right of the screen to see what we can do for you!

Friday, December 11, 2009

Isolating Switches

Here are stationary and movable contacts to what the customer identified as an Isolating Switches. All the burned up areas were repaired and given silver plating.

Monday, November 9, 2009

Westinghouse Air circuit Breaker Electrical Contacts

These W/H ACB Stationary and Movable Contacts are tipped with silver tungsten pads.

Friday, November 6, 2009

ITE 5HV-250 Electrical Contacts

Recently repaired ITE 5HV-250 Stationary Main Contacts.

Thursday, November 5, 2009

General Electric Electrical Contacts

These General Electric Contact Set were repaired with Silver Tungsten Tips.

Wednesday, November 4, 2009

GE Magne Blast Movable Arcing Electrical Contacts

Recently repaired movable arcing electrical contacts are from a General Electric Magne Blast circuit breaker.

Monday, November 2, 2009

Electrical Contacts for an AKR-30

Here is a sampling of General Electric electrical contacts from an AKR-30. Movable contacts, stationary contacts and the inner and outer pivots were repaired and silver plated. Check out our main site to see what we can do for you!

Friday, October 30, 2009

Siemens LA 25 Movable Contacts

These are off a siemens LA-25 Breaker. They are the movable contacts and were repaired with silver tungsten.

Monday, October 26, 2009

Electrical Contacts from a Diverter Switch

Here we have four different styles of contacts from a Diverter Switch we made in shop -- complete with contact pads and silver plated. The customer was basically a "middle man" who didn't know exactly who the OEM was. He sent in a sample of each style and we made these based on his samples.

Monday, October 19, 2009

GE AKR Stationary Arcing and ALF Upper Field Electrical Contacts

We repaired twelve GE AKR Stationary Arcing Contacts (five LHS, five RHS, and two centers) as well as one GE ALF Upper Field Contact Stud with appropriate contact tip material. Give us a call to see what we can do for you in repairing burned up electrical contacts!

Friday, October 16, 2009

General Electric Motor Starters

Recently repaired General Electric Size 7 Motor Starters

Thursday, October 15, 2009

Tap Changer Electrical Contacts

Below are some parts from two different tap changers. The basic hardware with the bolts could be reused, but the blades themselves were too badly burned. We replaced the copper blades with new versions which were cut to the OEM specifications. We also silver plated all the parts in shop.


Wednesday, October 14, 2009

General Electric Limit Amp Electrical Contacts

We can repair and manufacture various GE Limit Amp Electrical Contacts. Shown is one of the most common, OEM part number 167A9956G1.

Tuesday, October 13, 2009

Mallory 8CC Electrical Contacts

Here are some movable and stationary Mallory 8CC Electrical Contacts. We often repair these complete with silver plating. The particular set seen here was used in Lexington Fire Pump, circa 1948. The customer sent them in thinking we would have to make brand new ones based on the old burned up parts. While we could have made new versions, the older parts were salvageable. This resulted in a faster turn around time and saved the customer money.

The first shot is how the contacts looked when they came to WW Components, and the second shot shows the exact same contacts after we refurbished them.

Mallory 8CC Electrical Contacts -- before.

Mallory 8CC Electrical Contacts -- after!

Monday, October 12, 2009

Siemens 456D Electrical Contacts

Recently repaired Siemens 456D Electrical Contacts

Friday, September 25, 2009

General Electric FKD Contact Set

This is one of the most common types of contacts we work on; the electrical contacts from a General Electric FKD oil circuit breaker. The set above is how they generally come in to our shop. Thirty-six stationary contacts and six small arcing contacts in their aluminum housings and six movable rods make up the set. We completely disassemble, repair the contacts with the proper silver tungsten, and reassemble so they're ready for instillation. Below are the same contacts after we repaired them...

General Electric FKD Stationary Contact Assemblies

General Electric FKD Movable Contact Rods

Wednesday, September 23, 2009

Allis Chalmers BZ-40-A Contacts

Here are some contacts from a set of Allis Chalmers BZ-40-A Oil Circuit Breaker we repaired. The pads on the stationary double contact were burned up. We upgraded from plain copper to the appropriate tungsten contact. The movable rods were also in bad shape, but after our repairs, they look brand new. With the proper contact material, they will even operate better than before! Check out the contact info to the right and call us to see what we can do for you!

Tuesday, September 22, 2009

Federal Pacific OCB Shoe Contacts


An assortment of Federal Pacific OCB Contacts a.k.a. "shoe contacts". We can manufacture and repair various styles of these contacts. The one front and center is FB-4461, an example from a FP Model #RHE-78-115-10000. Check out the contact information to the right and call or email for a quote today!

Friday, September 11, 2009

General Electric FH-209 Brass Contact Assemblies

Here are three examples of General Electric FH-209 Brass Contact Assemblies we made using brass and copper layered shunts. Everything you see in the photo came from our shop -- completely assembled and ready for the customer.

Thursday, September 10, 2009

Westinghouse Size 5 Motor Starters

This is rather common job for us at WW Components; repair of the Westinghouse Size 5 Motor Starter contacts. These often arrive with burned up round pads, but we put on brand new silver tungsten pads with the proper contours. Check out our contact information to the right and give us a call!

Thursday, September 3, 2009

Cutler Hammer Size 3 (6-43-6) Three-pole set of electrical contacts

These Cutler Hammer contacts were repaired with silver tungsten pads and silver plated.

Westinghouse DS-416 Arcing Contacts

This is for a Westinghouse DS-416 Circuit breaker. We have three movable arcing contacts and three right-hand and three left-hand stationary arcing contacts. They all have silver tungsten pads and are silver plated. We can repair the contacts from all of the various Westinghouse DS types.

Wednesday, September 2, 2009

Allen-Bradley 100-Line Motor Starter Contacts

This is a Three-pole set of Allen Bradley 100-Line Motor Starter contacts. They were repaired with silver tungsten pads and silver plated.

Tuesday, September 1, 2009

GE AK-2-25 Electrical contacts

We manufactured these for a GE AK-2-25 Electrical circuit breaker. Three movable assemblies and six right-hand and six left hand stationary contacts. The pads are silver tungsten.

GE AK-2-25 Movable Assemblies and Stationary Electrical contacts

Wednesday, August 26, 2009

Siemens SDO Electrical Contacts

Two sets of Siemens SDO Oil Circuit Breaker electrical contacts repaired with brand new pads and silver plated.

Tuesday, August 25, 2009

Furnas Size 5 motor starter electrical contacts

Furnas size 5 (75KB14 )Motor Starter contacts. We can repair different sizes and OEM motor starter contacts from size 0 all the way up to size 9 and everything in between! Check out our main website on more of our services!

Wednesday, August 19, 2009

ITE K-1600 Movable Arcing Electrical Contacts

Three Movable Arcing Contacts repaired with Silver Tungsten pads.

Tuesday, August 18, 2009

GE Magne Blast AM-4.16 Movable Arcing Electrical Contacts

These GE AM-4.16-350 Movable Arcing Contacts were repaired with Silver Tungsten pads and then Silver Plated.

Monday, August 17, 2009

GE Magne Blast AM-4.16 Electrical Contacts

Three Movable Arcing contacts from a GE Magne Blast AM-4.16-250 breaker repaired with Silver Tungsten pads.

Friday, August 14, 2009

Stationary Switch Electrical Contacts

Three spring loaded stationary contacts for a USCO switch. We repaired the burned up area and silver plated the copper.

Thursday, August 13, 2009

Hubbell DC Electrical Contacts

A set of Hubbell DC Contactor contacts with brand new pads. Check out our contact information to the right and see what we can do for you.

Tuesday, August 11, 2009

K-600 Movable Arcing Electrical Contacts

ITE K-600 Movable Arcing Electrical Contacts. We can repair all of the K-600 contacts, but the movable arcing is the most requested. Check out our website to see what we can do for you.

Monday, August 10, 2009

Magne Blast Main Electrical Contacts

Twelve newly repaired GE Magne Blast movable main electrical contacts. We can refurbish the different Magne Blast contacts from various breaker types. Check out our main website on more of our services!

Friday, August 7, 2009

MA-350C Electrical Contacts

Here is a set of Siemens MA-350C Arcing Contacts that we recently repaired with brand new pads - three left hand movable arcing, three right hand movable arcing, and three stationary arcing. Check out our website to see what we can do for you.

Wednesday, July 22, 2009

IC7162 Limitamp Controllers

Some before and after shots of a set of GE IC7162 Limitamp Controllers GEH-3065 we recently refurbished. We repaired the old copper make up areas with silver tungsten pads. Check our our site: WWComponents.net to see what we can do for you!


Tuesday, June 23, 2009

ITE HK Contact Set

A portion of ITE HK Contacts we recently repaired. See the information on the sidebar to call for a quote today on repairing YOUR electrical contacts!

Monday, June 8, 2009

AKR10D-50H Electrical Contacts


Here's a group of contacts from a set of General Electric AKR-10D-50H. All contacts were given brand new pads. After they were plated and cleaned up, they looked and worked like a brand new set!

Thursday, May 28, 2009

Westinghouse DBF-40 Arcing Contacts


Here are some Westinghouse DBF-40 stationary and movable arcing contacts we recently repaired. They came in with bad pitting all along the makeup areas. We removed the old pads and replaced them with brand new contact material.

Friday, March 20, 2009

Cutler Hammer Contacts

Here are some Culter Hammer upper and lower stationary main contacts attached to a phenolic board along with the movable contacts with studs. These normally arrive with small circular pads as the contact points. We can repair these with full surface pads on the stationary contacts.

Monday, March 9, 2009

GM-7S Stationary Contact

Here is part of a Westinghouse GM-7S Stationary Contact. We repaired a whole set of these along with the movable stabs recently. The contact tips were replaced and all the hardware was cleaned up. The finished assemblies looked and operated as brand new products.

Friday, March 6, 2009

USCO Switch Repair

Below are before and after shots of a USCO HH6 600 AMP switch. We repair these as well as 1200 AMP versions for various customers. If the copper blades are too burned up, we can make new ones and reuse the cast hardware. We also do our own silver plating using 99.9% pure silver.
